163 / 208
Your One Stop Supply Shop”
163
Aluminium Oxide
is designed to
sharpen bench chisels, carving
tools and plane irons. Work your
way from lower grits. To achieve a
fine finish use a 240 grit belt.
Ceramic
is a great choice for re-
profiling damaged tools. The
heavier 60 grit option is an effi-
cient choice for removing material,
while the finer 120 grit will provide
a good finish.
Trizact
is designed to handle the
demands of all steels. Not strictly
‘grits’, these belts are built using
brick and pyramid abrasive shap-
ing. The highest 3000‘grit’will sharpen to two microns
(same sharpness as a disposable razor blade) & provide
a factory finish on all steels.
Robert Sorby Pro Edge Sharpening System
ProEdge Sharpening System
The Robert Sorby ProEdge System offers effortlessly repeatable sharpening every time.
Hugely versatile, this industrial strength machine is built to last and delivers astound-
ing“factory finish”results without fail. Perhaps the most simple to use sharpener on the
market, this system replicates the industry standard of achieving a flat grind using the
preferred method of belts over traditional grinding wheels. Sharpens bench, framing,
carving and turning chisels, drill bits, plane irons, knifes and garden tools..
11116
Robert Sorby ProEdge Sharpening System PEDO1C
............................ $529.99
You can use the factory presets or you can adjust
the unit exactly to your specific tool needs.
Both jigs give you the ability to sharpen specific
turning tool for the perfect keen edge.
Features and benefits
:
•
Sharpens with belts rather than abrasive wheels
•
Cuts steel rather than rubbing it off
•
Change belts in seconds
•
Flat bevel rather than hollow grind
•
Wide range of grits and abrasives
•
Sharpens all exotic alloys and carbide*
•
Belt sharpening lowers risk of overheating
•
Patented angle setter guarantees repeatability
•
Sharpen at exactly the same angle every time
•
Nine factory settings provide a guide for all types of tool
•
Can be locked between indexes for custom settings
•
Exceptional Robert Sorby construction
•
Built from solid steel
•
Pivots for operator comfort
•
Inexpensive to run
•
Small workbench footprint
•
Backed by Robert SorbyWarranty
*Carbide tools must be sharpened w/ diamond grit
abrasive belt (sold separately)
ProEdge Sharpening System Includes
:
•
1 each ProEdge Sharpening Machine
•
1 each Standard Gouge Jig
•
1 each Skew Jig
•
1 each Aluminum Oxide 120 Grit abrasive belt
•
1 each Zirconium 60 Grit abrasive belt
Factory Presets
make setup quick and easy
Includes a
Gouge and a Skew Jig
Available
individually or as a
convenient set!
Perfect for pocket
knives, carving knives
and smaller blades
ProEdge Abrasive Belts
ProEdge Buffing Accessories
ProEdge Long Grind Jig
Sorby Tool Tip Holder
ProEdge Small Knife Jig
Using the long grind jig on the Fingernail Profiler,
Deluxe Universal Sharpening System or the ProEdge
allows for three different types of profile to be pro-
duced on bowl and spindle gouges. It will produce a
fingernail profile, a long grind and an extra long grind
depending on which location hole the profile arm is
used. It fits onto the bar in replacement of the origi-
nal fingernail jig that is standard on either of the two
sharpening systems and is used in exactly the same
way but with the three options.
The Tip Holder is a great and inexpensive sharpening
accessory. Being double ended it allows the turner to
hold comfortably almost every Robert Sorby tool tip
without the fear of catching fingers on a sharpening
belt or a grinding wheel. This useful addition can be
used to hold an array of cutters. Please note: This is
NOT the same tip holder as used with the TurnMaster.
The knife jig consists of a back plate, raised wear plate,
universal arm and knife holder. The kit comes with a
set of full instructions and a video instruction can be
seen on Robert Sorby’s YouTube site. The small knife
holder is ideal for pocket knives, carving knives and
blades up to 8”long.
The Pigtail Mandrel, The Buffing Mop and The Ultra
Fine Buffing Compound all together allow you to con-
vert the Sorby ProEdge Sharpening System into a tool
buffing work station. The Pigtail Mandrel is used to
attach the Buffing Mop to the ProEdge machine. The
BuffingMop stays in placewithout the use of any tools.
Simply apply the Buffing Compound to the Buffing
Mop while it is spinning and start buffing to achieve
a high polish sheen on any steel tool. The mandrel,
mop and compound can be purchased separately or
as a set.
11117
Aluminum Oxide 60 Grit Belt
......................$7.99
11118
Aluminum Oxide 120 Grit Belt
...................$7.99
11119
Aluminum Oxide 240 Grit Belt
....................$7.99
11120
Ceramic 60 Grit Belt
...................................$12.99
11121
Ceramic 120 Grit Belt
.................................$12.99
11122
Trizact 600 Grit Belt
....................................$19.99
11123
Trizact 1200 Grit Belt
..................................$21.99
11124
Trizact 3000 Grit Belt
..................................$21.99
11157
Diamond Grit Belt
....................................$179.99
11128
Pigtail Mandrel
...........................................$24.99
11129
Buffing Mop
..............................................$19.99
11131
Ultra-Fine Buffing Compound
....................$9.99
11132
Buffing Kit
(includes11128,11129&11131)
...........$49.99
11126
Long Grind Jig
............................................$19.99
11127
Sorby Tip Holder W472
..............................$12.99
11130
ProEdge Small Knife Jig
.............................$99.99
Aluminum
Oxide
Ceramic
Trizact
Turnmaster Tip Holder
Short Edge Platform
This handy sharpening accessory allows you to hold
nearly every TurnMaster tip without fear of catching
the cutting tip - or even more importantly, your finger
- in a sharpening belt or grinding wheel. The tip of the
holder is narrow, so as not to get in the way. Designed
for the Sorby ProEdge Sharpening System.
The Short Edge Platform is ideal for tools with shorter
blades. The platform is only 1” wide making it perfect
for mini and midi sized tools.
11125
Short Edge Platform ...........................................
$32.99
11037
Turnmaster Tip Holder RSTM-TH .....................
$9.99
Turning Tool Sharpening
